Qingdao Wish Auto Parts Co., Ltd. is one of the leading manufacturers and suppliers of hi performance scalloped rotors in China, featured by quality products and good price. If you're going to buy the newest hi performance scalloped rotors made in China, welcome to get pricelist from our factory. Customized orders are welcome.
Specification
|
Product Overview |
|
|
Products Name |
Front 2-Piece Scalloped Brake Rotors - Pair (350x34) |
|
Product Name |
Front 2-Piece Scalloped Brake Rotors - Pair |
|
Product Code |
4M0615301AB/ 4M0615301AN/ 4M0615301P/ 80A615301G |
|
OE Number Example |
4M0615301AN |
|
Brand |
WISHBRAKE |
|
Disc Type |
Front Axle, Vented |
|
Material |
G3000/ G3500/ GG15HC/ GG20HC |
|
Technical Specifications |
|
|
Outer Diameter |
349mm |
|
Disc Thickness |
34mm |
|
Minimum Thickness |
32mm |
|
Overall Height |
57.1mm |
|
Center Bore Diameter |
68mm |
|
Mounting Holes |
5 |
|
PCD / Bolt Pattern |
112mm |
|
Disc Type |
Front Axle, Vented |
|
Material |
G3000/ G3500/ GG15HC/ GG20HC |
|
Weight |
12.7kg |
|
Vehicle Compatibility |
|
|
Make |
Volkswagen; Audi |
|
Model |
Touareg (CR7), A4 Allroad (8WJ), A4 Allroad (B9, 8WH), A5 Coupe (F53), A5 Sportback (F5A), A8L Sedan (4N8), A8L Sedan (4NL), Q7 (4MB), S4 Sedan (8W2), S4 Sedan (8WC), S4 Avant (8WD), S5 Coupe (F53), S5 Coupe (F5P), S5 Cabriolet (F57), S5 Cabriolet (F5E), S5 Sportback (F5A), S5 Sportback (F5F), SQ5 (FYG), A4 Allroad B9 (8WH, 8WJ), A4 B9 (8W2, 8WC), A4 B9 Avant (8W5, 8WD), A5 (F53, F5P), A5 Sportback (F5A, F5F), Q7 (4MB, 4MG, 4MQ) |
|
Generation |
8WH, 8WJ, 8W2, 8WC, 8W5, 8WD, F53, F5P, F5A, F5F, 4MB, 4MG, 4MQ |
|
Year |
2015-2023 |
|
Engine |
New |
|
Commercial Information |
|
|
MOQ |
2 Pcs |
|
Sample Availability |
Yes |
|
Packaging |
OEM Packaging |
|
Delivery Time |
7-15 Days |
|
Warranty |
80000kms |
|
OEM/ ODM |
Yes, Support |
OE-matched scalloped brake rotors, comprehensive OE number coverage, direct bolt-on upgrade for compatible vehicles Unlike existing modified rotors, each and every WishBrake scalloped rotor is checked on run out, dynamically balanced and inspected for thickness variation. We are able to supply ECE R90 registered batches for EU aftermarket use. For full competition spec (strictly open-wheel) clear race-only scalloped rotors SKUs are available.
Product feature and application
Friction Face freedom: scallop is on perimeter. this allows freely blending with venting, drill pattern and slot pattern without destroying main friction band. Anything designed by WishBrake would not induce stress riser cracking at the transition zone.
Production details
Typical low quality competitor shortcut we would never do Scallops cut after full finish without stress-relief, or doing it with cheap one piece rotors, no balance correction. That will cause vibration, cracking, customer cannot believe.
Product qualification
• Selected SKUs available with full ECE-R90 test report for EU aftermarket import
• Cast iron material mill sheet & hardness record per batch
Reduce unsprung mass, improve airflow & debris clearance, compatible for premium performance vehicles, E Mark R90 available.
We also share installation best practice for performance rotors: proper bedding procedure, torque sequence, compatible pad recommendation.
FAQ
Q: Can I order custom scallop shape / custom diameter / custom logo?
A: Yes this is one of our strong ODM product lines for tuning distributors. Minimum order applies for fully custom profile.
