Qingdao Wish Auto Parts Co., Ltd. is one of the leading manufacturers and suppliers of iatf 16949 brake discs in China, featured by quality products and good price. If you're going to buy the newest iatf 16949 brake discs made in China, welcome to get pricelist from our factory. Customized orders are welcome.
Specification
|
Product Overview |
|
|
Products Name |
IATF 16949 brake discs |
|
Product Name |
large size brake disc for trucks |
|
Product Code |
4246.N0 |
|
OE Number Example |
4246.N0 |
|
Brand |
WISHBRAKE |
|
Disc Type |
Front Axle, Vented |
|
Material |
G3000/ G3500/ GG15HC/ GG20HC |
|
Technical Specifications |
|
|
Outer Diameter |
283mm |
|
Disc Thickness |
26mm |
|
Minimum Thickness |
24.2mm |
|
Overall Height |
28.2mm |
|
Center Bore Diameter |
66mm |
|
Mounting Holes |
4 |
|
PCD / Bolt Pattern |
108mm |
|
Disc Type |
Front Axle, Vented |
|
Material |
G3000/ G3500/ GG15HC/ GG20HC |
|
Weight |
7kg |
|
Vehicle Compatibility |
|
|
Make |
CITROEN;PEUGEOT |
|
Model |
- |
|
Generation |
- |
|
Year |
- |
|
Engine |
New |
|
Commercial Information |
|
|
MOQ |
2 Pcs |
|
Sample Availability |
Yes |
|
Packaging |
OEM Packaging |
|
Delivery Time |
7-15 Days |
|
Warranty |
80000kms |
|
OEM/ODM |
Yes, Support |
We offer both Performance front discs and internally Sport front discs. We do the service for broad mainstream passenger vehicle lines, alongside premium European passenger cars. This is not a dedicated race rotor programme.
WishBrake IATF 16949 brake discs represent a full quality managed brake rotor series manufactured strictly under IATF 16949 automotive quality management system framework. For global auto parts importers, repair chain operators and aftermarket distributors, because this standard is originally formulated for original equipment automotive supply chains, bringing OE aligned quality thinking into aftermarket replacement brake disc production.
|
Item |
Details |
|
Brand |
WishBrake |
|
Product Name |
IATF 16949 Brake Discs / IATF Certified Brake Rotors |
|
Product Category |
Brake Rotors by Certified |
|
Applicable Axle |
Front / Rear Axle |
|
Material |
G3000 / HT250 High‑Carbon Grey Cast Iron |
|
Disc Structure |
Solid / Vented / Two‑Piece Floating per OE drawing |
|
Surface Options |
Plain Machined, Geomet Coated, Zinc‑Plated, Painted Anti‑Rust |
|
Certification |
IATF‑16949, ISO9001, selected SKUs ECE R90, SGS test report available |
|
HS Code |
8708309990 |
Surface treatment options are fully included within IATF managed workflows. Anti‑corrosion coating processes such as Geomet and zinc plating implement batch wise coating layer thickness and adhesion testing. Coating procedure parameters are documented; finished coated rotors pass salt spray sampling validation. Such controls reduce coating peeling, blistering and premature rust complaints for markets with coastal humid climate or winter road‑salt application.
Factory wide IATF 16949 automotive quality system governance
All WishBrake IATF certified rotors are produced inside IATF 16949 audited manufacturing premises. Raw material supplier evaluation, incoming inspection, casting process, CNC machining, testing procedure and non conformity disposal are all executed according to standardized system documents. This greatly reduces batch to batch performance fluctuation which frequently troubles ordinary aftermarket brake disc products.
Raw material incoming audit & sampling inspection
Raw material suppliers pass periodic system oriented evaluation. Each smelting lot receives chemical composition sampling test. Unqualified raw material batches get rejected before feeding into furnaces. Test data are filed for traceability, complying with IATF 16949 record retention requirements.
Casting & stress relief heat treatment process
Molten iron is poured into precision mould cavities according to OE reference structure. After casting blank forming, work pieces go through standardized stress relief heat treatment procedure to release internal casting stress, mitigating hidden post machining deformation risk. Heat treatment temperature time curve parameters are recorded for every production batch.
Document & Material Support For Business Partners
WishBrake can supply factory workshop real scene photos, production line video clips, lab test report copies and certification scans for global B2B partners'sales material production or local market supplier qualification filing.
Above qualification resources provide solid confidence for Compatible vehicles overseas importers who source IATF certified brake disc products from WishBrake.
Pre order consultation, quotation and qualification document support
Customers may provide target OE number list, vehicle VIN information or sample pictures. WishBrake sales technical team confirms fitment status, stock situation or production cycle, and issues formal quotation including unit price, MOQ and lead time. If clients need certification copies for local supplier qualification filing, relevant document scans can be supplied at quotation phase. Custom surface treatment or special laser marking requirements are confirmed in advance.
Many practical benefits can IATF 16949 certified rotors bring for your import business.
Many regional repair chain purchasers and vehicle fleet tender projects set IATF 16949 as supplier entry threshold. Meanwhile system controlled production improves batch to batch consistency, reduces after sales complaint probability, and complete batch traceability supports you to handle local market quality supervision audit when necessary.
Enhanced sampling test scheme for surface coated IATF 16949 brake discs
Aiming at market feedback from high humidity coastal regions, WishBrake raises sampling ratio for salt spray anti rust performance test for Geomet coated and zinc plated IATF 16949 brake disc batches, further lifting anti corrosion reliability for coated variant products.
