Qingdao Wish Auto Parts Co., Ltd. is one of the leading manufacturers and suppliers of oe standard discs in China, featured by quality products and good price. If you're going to buy the newest oe standard discs made in China, welcome to get pricelist from our factory. Customized orders are welcome.
Specification
|
Product Overview |
|
|
Products Name |
OE standard discs |
|
Product Name |
brake rotors |
|
Product Code |
6384230112 |
|
OE Number Example |
6384230112 |
|
Brand |
WISHBRAKE |
|
Disc Type |
Rear Axle, Solid |
|
Material |
G3000/ G3500/ GG15HC/ GG20HC |
|
Technical Specifications |
|
|
Outer Diameter |
280mm |
|
Disc Thickness |
10mm |
|
Minimum Thickness |
8mm |
|
Overall Height |
63.4mm |
|
Center Bore Diameter |
67mm |
|
Mounting Holes |
5 |
|
PCD / Bolt Pattern |
112mm |
|
Disc Type |
Rear Axle, Solid |
|
Material |
G3000/ G3500/ GG15HC/ GG20HC |
|
Weight |
4.3kg |
|
Vehicle Compatibility |
|
|
Make |
MERCEDES BENZ |
|
Model |
- |
|
Generation |
- |
|
Year |
- |
|
Engine |
New |
|
Commercial Information |
|
|
MOQ |
2 Pcs |
|
Sample Availability |
Yes |
|
Packaging |
OEM Packaging |
|
Delivery Time |
7 15 Days |
|
Warranty |
80000kms |
|
OEM/ODM |
Yes, Support |
We offer both Steel front discs and internally Cast Iron front discs. We do the service for broad mainstream passenger vehicle lines, alongside premium European passenger cars. This is not a dedicated race rotor programme.
Dimensional accuracy determines installation success. WishBrake enforces strict control over disc thickness tolerance, total lateral run out, DTV (disc thickness variation), hub face perpendicularity, PCD bolt hole circle and mounting hole position accuracy. Every finished rotor goes through run out inspection and dynamic balance testing. Poor dynamic balance will trigger steering wheel shaking under braking at medium high speed, a frequent complaint from end users who purchase low grade aftermarket rotors. By replicating OE dynamic balance standards, WishBrake minimizes post installation vibration risks for end users.
Market oriented adaptability is built into the product planning. WishBrake OE spec brake rotor catalogue covers thousands of OE numbers, do the service for mainstream European premium brands, North American passenger vehicles, Asian market sedans and sport oriented models. Importers can source front axle and rear axle OE spec replacement discs for ordinary family cars as well as high end performance vehicles. Wholesale oriented MOQ policies support mixed batch ordering of multiple OE part numbers, assisting overseas distributors to enrich their spare parts shelf inventory without excessive single SKU stocking pressure.
Multiple surface treatment options for diverse regional climate demands
WishBrake provides plain machined, Geomet coating, zinc plated and painted anti rust treatments for rotor hats and outer edge non friction areas. For coastal high humidity regions or winter road salt using markets, coated OE spec rotors effectively suppress premature surface rust on non friction zones, improving visual appearance and slowing down corrosion caused ageing. The friction working surface maintains precision machined state to preserve original friction interface performance.
Final visual inspection & export oriented packing
Workers visually check finished product for machining scratch, coating layer defect, casting defect. Qualified rotors go into neutral export carton; stack onto wooden pallets for sea freight transportation. Anti collision protective material reduces cross border transport damage probability.
Detail difference compared with generic low grade aftermarket discs: WishBrake controls casting blank stress relief heat treatment procedure; many low cost factories skip full stress relief step, leading to hidden deformation risk after long term vehicle running.
Raw material quality control mechanism
Every batch of incoming casting raw material carries out component sampling inspection. Reject raw material batches that cannot meet OE spec chemical composition requirement, avoid unstable material source causing large batch product quality fluctuation.
Packing & logistics solution
Standard packing: neutral export carton + wooden pallet. Support FCL full container loading and LCL mixed goods container loading. Main shipment port is Qingdao port. According to client requirement, can cooperate with designated freight forwarder or recommend cooperative logistics partner.
WishBrake can develop OE spec rotor for less common vehicle model with rare OE number.
Customers can provide original rotor physical sample or OE drawing document. WishBrake technical team will carry out reverse engineering assessment, give trial production cost and lead time suggestion. Small batch trial order is acceptable.
Mixed SKU small batch order mode promotion for medium and small scale auto parts distributors
WishBrake optimizes internal production scheduling logic, improve support capacity for multi OE number mixed small batch order. This policy helps medium small size overseas business partners enrich their spare parts inventory without undertaking large single SKU stock pressure.
